Installing the Keyboard
1. Tighten the screws to secure the keyboard to the palmrest assembly.
2. Affix the Mylar sheath to the screws on the keyboard.
3. Affix the Mylar tape to the keyboard.
4. Install the:
a) system board
b) hard drive
c) battery
d) base cover
5. Follow the procedures in
After Working Inside Your Computer.
Removing the Display Assembly
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove the:
a) base cover
b) battery
3. Disconnect and remove the following cables:
a) antenna cables from the WLAN card
b) touch-panel cable and display cable from the system board
c) camera cable from the I/O board
29
