Dell Pro 14 Premium - Installing the Heat Sink

Obrázek 35. Removing the heat sink
Kroky
1. In reverse sequential order (3>2>1), loosen the three captive screws that secure the heat sink to the system board.
2. Lift the heat sink off the system board.
Installing the heat sink
VÝSTRAHA: The information in this section is intended for authorized service technicians only.
Požadavky
If you are replacing a component, remove the existing component before performing the installation process.
O této úloze
The following image indicates the location of the heat sink and provides a visual representation of the installation procedure.
Demontáž ainstalace jednotek vyměnitelných vterénu (FRU)
67
