Left
Obrázek 2. Left view
1. HDMI 2.1 port
Connect to a TV, external display, or another HDMI-in enabled device. Provides video and audio output.
2. Universal audio port
Connect headphones or a headset (headphone and microphone combo).
3. Battery indicator LED
Indicates the battery-charge status.
Solid amber-Battery charge is low.
Off-Battery is fully charged.
4. Thunderbolt 4 port with DisplayPort Alt Mode/USB4/Power Delivery
Supports USB4, DisplayPort 1.4, Thunderbolt 4 and also enables you to connect to an external display using a display adapter. Supports
data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4.
POZNÁMKA:
You can connect a Dell Docking Station to the Thunderbolt 4 ports. For more information, search in the Knowledge
Base Resource at Dell Support Site.
POZNÁMKA: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
POZNÁMKA: USB4 is backward compatible with USB 3.2, USB 2.0, and Thunderbolt 3.
POZNÁMKA: Thunderbolt 4 supports two 4K displays or one 8K display.
8 Pohledy na počítač Dell Pro 14 Premium PA14250
