P
aper jam in the staple finisher
1
R
emove the jammed paper
.
Note:
Make sure that all paper fragments are removed.
2
Open the rear staple finisher door
.
3
R
emove the jammed paper
.
Note:
Make sure that all paper fragments are removed.
Clearing jams
168
167
169
