Dell XC Core XC760

Table 6. Components inside the system(continued)
Item Description
14 System board
15 Cooling fan cage assembly
16 Backplane
17 Express Service Tag
Figure 8. Inside the system with full length risers and GPU shroud
Table 7. Components inside the system with full-length risers and GPU shroud
Item Description
1 Backplane
2 Rear mounting front PERC module
3 Cooling fans
4 GPU air shroud
5 Expansion riser 4
6 Expansion riser 3
Dell XC Core XC760 overview 15
