Dell XC Core XC760

GPU kit
The GPU full-length kit is available. Depending on the kit ordered, the respective components are available.
WARNING: Do not install or use a consumer-grade GPU in Enterprise Server products.
CAUTION: Do not install GPUs, network cards, or other PCIe devices on your system if Dell has not validated
and tested them. If the installation of unauthorized and invalidated hardware causes damage, the system
warranty is voided.
Table 58. Components in the full length (FL) GPU kit
Components GPU full-length kit
Details Quantity
Risers Riser configuration (RC)
3-2, 5-2*, or, 10-2*
RC 3-2: R1P (FL) + R2A (HL) + R3B (HL) + R4P** (FL)
RC 5-2: R1R (FL) + R2A (HL) + R3A (FL) + R4P*^ (FL)
RC 10-2: R1P
^
(FL) + R2A (HL) + R4R (FL)
Shroud GPU shroud 1
Fans HPR GOLD fan 6
Heat sink L-type heat sink
for processor 1 and
processor 2
RC 3-2, 5-2: 2
RC 10-2: 1
Cables Power cable 2 x 4 (8-position) or 2 x 6 + 1 x 4 (12-position + 4-sideband)
FL - Full Length, HL - Half Length, HPR - High Performance, RC - Riser configuration
* The 5-2 configuration supports DW GPU only on slots 7 and configuration 10-2 supports DW GPU only on slot 2.
** R1P and R4P support Double Width (DW) GPU.
The power cable is imprinted with the following connections:
● Connector on the system board
● GPU connection
See the GPU power cable matrix table for the power cable required for your GPU.
Populate only processor 1 slot in RC10-2, as it only supports a single processor configuration.
Serial COM port kit
The serial COM port kit contains the following components.
Table 59. Serial COM port kit
Components Quantity
Serial COM port card 1
Cable 1
VGA port kit
The VGA port kit contains the following components.
