Dell XC Core XC760

Table 56. Configuration 11: R1 paddle+R2A+R3B+R4 paddle(continued)
Card type Slot priority Maximum number of cards
Broadcom (NIC: 25Gb) 6, 3 2
Broadcom (NIC: 10Gb) 5, 4 2
Broadcom (NIC: 10Gb) 6, 3 2
Broadcom (NIC: 10Gb) 5, 4, 6, 3 4
Broadcom (NIC: 10Gb) 5, 4 2
Broadcom (NIC: 10Gb) 6, 3 2
Intel (NIC: 10Gb) 5, 4 2
Intel (NIC: 10Gb) 6, 3 2
Intel (NIC: 10Gb) 5, 4 2
Intel (NIC: 10Gb) 6, 3 2
Intel (NIC: 1Gb) 5, 4 2
Intel (NIC: 1Gb) 6, 3 2
Intel (NIC: 1Gb) 5, 4 2
Intel (NIC: 1Gb) 6, 3 2
Broadcom (NIC: 1Gb) 5, 4 2
Broadcom (NIC: 1Gb) 6, 3 2
Foxconn (External Adapter) 5, 4, 6, 3 4
Removing the expansion card risers
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
3. Remove the air shroud or remove the GPU air shroud.
4.
NOTE:
If BOSS-N1 module is installed, be sure to disconnect the BOSS-N1 power cable and Signal cable before
removing the Riser 1 cage.
5. If applicable, disconnect the cables from the expansion card or system board.
