Figure 144. Installing GPU on Riser 1
3. To install the GPU on Riser 4:
a. Connect the GPU power cable to the GPU card.
b. Align the connector on the GPU with the connector on the riser.
c. Insert the GPU into the riser until firmly seated.
d. Tilt the expansion card holder latch.
e. Press the card holder latch to secure the GPU card to the riser.
f. Slide the expansion card latch on the riser.
Figure 145. Installing GPU on Riser 4
154
Installing and removing system components
