Delta AH Series Hardware Manual

Chapter 2 System Configuration
2-5
2
_
 Components
Component Model Name Description
Power supply
module
AHPS05-5A
100~240 VAC
50/60 Hz
AHPS15-5A 24 VDC
AH Motion
CPU
AHxxEMC-5A
AH08EMC-5A: 8 axes; AH10EMC-5A: 16 axes; AH20EMC-5A: 32 axes
One EtherCAT port
One EtherNet/IP port (adapter)
One built-in USB port (RS-232)
One built-in micro SD interface
Motion
backplane
AHBP03M2-5A Three slots available for additional AH500 series modules.
AHBP05M2-5A Five slots available for additional AH500 series modules.
AHBP07M2-5A Seven slots available for additional AH500 series modules.
Digital
input/output
module
AH16AM10N-5A
24 VDC
5 mA
16 inputs
Terminal block
AH32AM10N-5A
24 VDC
5 mA
32 inputs
Terminal block
AH32AM10N-5B
24 VDC
5 mA
32 inputs
DB37 connector
AH32AM10N-5C
24 VDC
5 mA
32 inputs
MIL connector
AH64AM10N-5C
24 VDC
3.2 mA
64 inputs
MIL connector
AH16AM30N-5A
100~240 VAC
4.5 mA~9 mA (100 V, 50 Hz)
16 inputs
Terminal block
AH16AN01R-5A
240 VAC/24 VDC
2 A
16 outputs
Relay
Terminal block
