A.1 EMC Standards for an AH Motion Controller System
A.1.1 EMC Standards Applicable to an AH Motion Controller System
The EMC standards which are applicable to an AH Motion Controller system are listed below.
 EMI
Port Frequency range Level (Normative) Reference standard
Enclosure port
(radiated)
(measured at a distance
of 10 meters)
30-230 MHz 40 dB (μV/m) quasi-peak
IEC 61000-6-4
230-1000 MHz 47 dB (μV/m) quasi-peak
AC power port
(conducted)
0.15-0.5 MHz
79 dB (μV) quasi-peak
IEC 61000-6-4
66 dB (μV) average
0.5-30 MHz
73 dB (μV) quasi-peak
60 dB (μV) average
 EMS
Environmental
phenomenon
Reference
standard
Test Test level
Electrostatic discharge
IEC 61000-4-2
Contact ± 4 kV
Air ± 8 kV
Radio frequency
electromagnetic field
Amplitude modulated
IEC 61000-4-3
80% AM,
1 kHz sinusoidal
2.0-2.7 GHz 1 V/m
1.4-2.0 GHz 3 V/m
80-1000 MHz 10 V/m
Power frequency magnetic
field
IEC 61000-4-8
60 Hz 30 A/m
50 Hz 30 A/m
