Delta AH Series Hardware Manual

AH Motion Controller – Hardware Manual
3-16
_3
3.2.7 Arrangement of Terminals
 AHxxEMC-5A
Pin Terminal
Function
Pin Terminal
Function
Pulse
Count
Pulse
Count
1
COM
COM
19
Y0.11
Out3
2 COM COM 20 Y0.10 Out2
3
COM
COM
21
Y0.9
Out1
4
COM
COM
22
Y0.8
Out0
5 S/S S/S 23 X1.3 CntA5
6
X1.5
Rst5
24
X1.2
CntA5
7
S/S
S/S
25
X1.1
CntA4
8
X1.4
Rst4
26
X1.0
CntA4
9
S/S
S/S
27
X0.15
DOG3
CntA3
10
X0.3
Rst3
28
X0.14
DOG2
CntA3
11
S/S
S/S
29
X0.13
DOG1
CntA2
12 X0.2 Rst2 30 X0.12
DOG0
CntA2
13
X0.1-
Rst1-
31
X0.1+
Rst1+
14
X0.11-
DOG5-
CntB1-
32
X0.11+
DOG5+
CntB1+
15 X0.10-
DOG4-
CntA1- 33 X0.10+
DOG4+
CntA1+
16
X0.0-
Rst0-
34
X0.0+
Rst0+
17
X0.9-
MPGB-
CntB0-
35
X0.9+
MPGA-
CntB0+
18 X0.8- MPGB+ CntA0- 36 X0.8+ MPGA+ CntA0+
3.2.8 Memory Card Slot
 AHxxEMC-5A
The AH Motion series CPU modules support micro SD cards. You can purchase products which meet the specifications
supported by the memory card slot on the AH Motion CPU.
SD Cards
SD cards have three size types: SD cards, miniSD cards, and microSD cards. The AH Motion CPU supports Micro SDHC
cards.
SD

MiniSD
MicroS
