Delta ASD-A2R-0421 Series - P1-XX Basic Parameters

Chapter 8 ParametersASDA-A2R Series
8-36 Revision December, 2014
Settings：
Bit0: SRDY (Servo is ready)
Bit1: SON (Servo ON)
Bit2: ZSPD (Zero speed detection)
Bit3: TSPD (Target speed reached)
Bit4: TPOS (Target position reached)
Bit5: TQL (Torque limit)
Bit6: ALRM (Servo alarm)
Bit7: BRKR (Brake control output)
Bit8: HOME (Homing finished)
Bit9: OLW (Early warning for overload)
Bit10: WARN (When Servo warning,CW, CCW, EMGS, under
voltage, Communication error, etc, occurs, DO is ON)
Bit11: Reserved
Bit12: Reserved
Bit13: Reserved
Bit14: Reserved
Bit15: Reserved
P1-xx Basic Parameters
P1-00▲
PTT The Type of External Pulse Input
Address: 0100H
0101H
Operational
Interface：
Panel / Software Communication
Related Section:
6.2.1
Default：
0x2
