Chapter 8 ParametersASDA-A2R Series
Revision December, 2014
8-117
Control
Mode：
ALL
Unit：
pulse
Range：
0 ~ 32767
Data Size：
32bit
Format：
DEC
Settings：
If the amount of pulse loss exceeds the setting level, it means the
pulse loses too much and AL.057 will occur.
※This function is available only when motor travels through Z
phase signal.
P2-83 Level Checked via Z
Address: 02A6H
02A7H
Operational
Interface：
Panel / Software Communication
Related Section: -
Default：
2000
Control
Mode：
ALL
Unit：
N/A
Range：
0 ~
31
2
Data Size：
32bit
Format：
DEC
Settings：
P2-84 LRSF Special Funciton of Low Resolution
Address: 02A8H
02A9H
Operational
Interface：
Panel / Software Communication
Related Section: -
Default：
0X0000
Control
Mode：
ALL
Unit：
N/A
Range：
0 ~0x011F
Data Size：
16bit
Format：
HEX
