Chapter 10 TroubleshootingASDA-A2R Series
10-14 Revision December, 2014
：IGBT Overheat
Causes Checking Method Corrective Actions
Over the rated loading of
the drive and
continuously excessive
using
Check if it is overloading or the
motor current is too high.
Increase the motor capacity or
reduce the load.
The drive output is
short-circuit
Check the drive output wiring Correct wiring
：Abnormal EEPROM
Causes Checking Method Corrective Actions
It is in error when DSP
accesses EEPROM.
Press the SHIFT Key on the
panel and it shows EXGAB.
X = 1, 2, 3
G＝group code of the parameter
AB＝hexadecimal of the
parameter
If it shows E320A, it means it is
parameter P2-10; If it shows
E3610, it means it is parameter
P6-16. Please check the
parameter.
The fault occurs when applying
to the power. It means one of the
parameters is over the
reasonable range. Please
re-power on after adjusting.
The fault occurs in normal
operation. It means it is in error
when writing the parameter. The
alarm can be cleared by
DI.ARST.
Abnormal hidden
parameter
Press the SHIFT Key on the
panel and it shows E100X
The fault occurs in parameter
reset. The setting of the drive is
wrong. Please set the correct
type of the drive.
Data in ROM is
damaged.
Press the SHIFT Key on the
panel and it shows E0001
The fault occurs when it is
servo-on. Usually it is because
the data in ROM is damaged or
there is no data in ROM. Please
send the drive back to the
distributors or contact with Delta.
