Appendix A AccessoriesASDA-A2R Series
Revision December, 2014
A-21
3kW servo drive and 3kW Medium-high-inertia Motor
Servo Drive ASD-A2R-3023-
Medium-high-inertia Motor
ECMA-F△1830S
Motor Power Cable (without brake) ASD-CAPW200X
Motor Power Cable (with brake) ASD-CAPW210X
Power Connector ASD-CAPW2000
Incremental Type Encoder
Connector
ASD-CAEN100X
Absolute Type Encoder Connector ASD-A2EB100X
Encoder Connector ASD-CAEN1000
(X=3 indicates that the cable length is 3m; X=5 indicates that the cable length is 5m)
Other Accessories (suitable for the whole series of ASDA-A2R)
Name Product Number
50 Pin I/O Connector (CN1) ASD-CNSC0050
Terminal Block Module ASD-BM-50A
RS-232 Communication Cable ASD-CARS0003
Software Communication Cable DOP-CAUSBAB
CANopen Communication Cable TAP-CB03 / TAP-CB04
CANopen Distribution Box TAP-CN03
RS -485 Connector ASD-CNIE0B06
Regenerative Resistor 400W 40Ω BR400W040
Regenerative Resistor 1kW 20Ω BR1K0W020
Regenerative Resistor 1.5kW 5Ω BR1K5W005
