Delta C2000 Plus Series User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-20
Model HP
Rated
Current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Input AC
reactor
Delta part #
Weight
(kg)
Heat
Dissipation
(W)
VFD750C43A-00
VFD750C43A-21
100 110 220 0.221 0.368 Yes DR110AP221 28 150
VFD900C43A-00
VFD900C43A-21
125 150 300 0.162 0.27 Yes DR150AP162 35 170
VFD1100C43A-00
VFD1100C43A-21
150 180 360 0.135 0.225 Yes DR180AP135 42 190
VFD1320C43A-00
VFD1320C43A-21
175 220 440 0.11 0.184 Yes DR220AP110 45 230
VFD1600C43A-00
VFD1600C43A-21
215 260 520 0.098 0.162 Yes DR260AP098 55 280
VFD1850C43A-00
VFD1850C43A-21
250 310 620 0.078 0.131 Yes DR310AP078 60 300
VFD2000C43A-00
VFD2000C43A-21
270 335 536 0.072 0.12 Yes DR370AP066
*1
75 340
VFD2200C43A-00
VFD2200C43A-21
300 370 740 0.066 0.109 Yes DR370AP066 75 340
VFD2500C43A-00
VFD2500C43A-21
340 415 664 0.058 0.10 Yes DR460AP054
*1
85 400
VFD2800C43A-00
VFD2800C43C-21
375 460 920 0.054 0.09 Yes DR460AP054 85 400
VFD3150C43A-00
VFD3150C43C-21
420 550 1100 0.044 0.074 Yes DR550AP044 95 430
VFD3550C43A-00
VFD3550C43C-21
475 616 1232 0.039 0.066 Yes DR616AP039 110 450
VFD4000C43A-00
VFD4000C43A-21
530 683 1092.8 0.036 0.06 Yes DR683AP036 130 480
VFD4500C43A-00
VFD4500C43C-21
600 683 1366 0.036 0.06 Yes DR683AP036 130 480
VFD5000C43A-00
VFD5000C43C-21
650 866 1732 0.028 0.047 Yes DR866AP028 170 610
VFD5600C43A-00
VFD5600C43C-21
750 930 1860 0.026 0.044 Yes N/A N/A N/A
Table 7-22
NOTE: *1: The inductance value for the above applications of Delta’s reactors will be close to, but less than 3%.
575V, 50/60 Hz, Three-phase
kW HP
Rated current (Arms)
Saturation
Current
(Arms)
3% impedance (mH) 5% impedance (mH)
Light
Duty
Normal
Duty
Heavy
Duty
Light
Duty
Normal
Duty
Heavy
Duty
Light
Duty
Normal
Duty
Heavy
Duty
VFD015C53A-21 2 3 2.5 2.1 4.2 8.806 10.567 12.580 14.677 17.612 20.967
VFD022C53A-21 3 4.3 3.6 3 5.9 6.144 7.338 8.806 10.239 12.230 14.677
VFD037C53A-21 5 6.7 5.5 4.6 9.1 3.943 4.803 5.743 6.572 8.005 9.572
VFD055C53A-21 7.5 9.9 8.2 6.9 13.7 2.668 3.222 3.829 4.447 5.369 6.381
VFD075C53A-21 10 12.1 10 8.3 16.5 2.183 2.642 3.183 3.639 4.403 5.305
VFD110C53A-21 15 18.7 15.5 13 25.7 1.413 1.704 2.032 2.355 2.841 3.387
VFD150C53A-21 20 24.2 20 16.8 33.3 1.092 1.321 1.572 1.819 2.201 2.621
690V, 50/60 Hz, Three-phase
kW HP
Rated current Saturation Current 3% Impedance 5% Impedance
(Arms) (Arms) (mH) (mH)
Light
Duty
Norma
l Duty
Heavy
Duty
Light
Duty
Norma
l Duty
Heavy
Duty
Light
Duty
Norma
l Duty
Heavy
Duty
Light
Duty
Norma
l Duty
Heavy
Duty
VFD185C63B-21 25 24 20 14 28.8 30.0 25.2 1.585 1.902 2.717 2.642 3.170 4.529
VFD220C63B-21 30 30 24 20 36.0 36.0 36.0 1.268 1.585 1.902 2.113 2.642 3.170
VFD300C63B-21 40 36 30 24 43.2 45.0 43.2 1.057 1.268 1.585 1.761 2.113 2.642
VFD370C63B-21 50 45 36 30 54.0 54.0 54.0 0.845 1.057 1.268 1.409 1.761 2.113
Table 7-23
