Delta C2000 Plus Series User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-21
kW HP
Rated current Saturation Current 3% Impedance 5% Impedance
(Arms) (Arms) (mH) (mH)
Light
Duty
Norma
l Duty
Heavy
Duty
Light
Duty
Norma
l Duty
Heavy
Duty
Light
Duty
Norma
l Duty
Heavy
Duty
Light
Duty
Norma
l Duty
Heavy
Duty
VFD450C63B-00
VFD450C63B-21
60 54 45 36 64.8 67.5 64.8 0.704 0.845 1.057 1.174 1.409 1.761
VFD550C63B-00
VFD550C63B-21
75 67 54 45 80.4 81.0 81.0 0.568 0.704 0.845 0.946 1.174 1.409
VFD750C63B-00
VFD750C63B-21
100 86 67 54 103.2 100.5 97.2 0.442 0.568 0.704 0.737 0.946 1.174
VFD900C63B-00
VFD900C63B-21
125 104 86 67 124.8 129.0 120.6 0.366 0.442 0.568 0.610 0.737 0.946
VFD1100C63B-00
VFD1100C63B-21
150 125 104 86 150.0 156.0 154.8 0.304 0.366 0.442 0.507 0.610 0.737
VFD1320C63B-00
VFD1320C63B-21
175 150 125 104 180.0 187.5 187.2 0.254 0.304 0.366 0.423 0.507 0.610
VFD1600C63B-00
VFD1600C63B-21
215 180 150 125 216.0 225.0 225.0 0.211 0.254 0.304 0.352 0.423 0.507
VFD2000C63B-00
VFD2000C63B-21
270 220 180 150 264.0 270.0 270.0 0.173 0.211 0.254 0.288 0.352 0.423
VFD2500C63B-00
VFD2500C63B-21
335 290 220 180 348.0 330.0 324.0 0.131 0.173 0.211 0.219 0.288 0.352
VFD3150C63B-00
VFD3150C63B-21
425 350 290 220 420.0 435.0 396.0 0.109 0.131 0.173 0.181 0.219 0.288
VFD4000C63B-00
VFD4000C63B-21
530 430 350 290 516.0 525.0 522.0 0.088 0.109 0.131 0.147 0.181 0.219
VFD4500C63B-00
VFD4500C63B-21
600 465 385 310 558.0 577.5 558.0 0.082 0.099 0.123 0.136 0.165 0.205
VFD5600C63B-00
VFD5600C63B-21
745 590 465 420 708.0 697.5 756.0 0.064 0.082 0.091 0.107 0.136 0.151
VFD6300C63B-00
VFD6300C63B-21
850 675 675 675 810.0 1012.5 1215.0 0.056 0.056 0.056 0.094 0.094 0.094
Table 7-24

Delta C2000 Plus Series Specifications

General

Altitude	Up to 1000m without derating
Communication	CANopen
Output Current	2.5A
Protection Features	Overcurrent, Overvoltage, Overtemperature
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	95% RH (non-condensing)
