Chapter 7 Optional AccessoriesC2000 Plus
7-95
Frame F
Applicable models: VFD900C23A-00; VFD1320C43A-00; VFD1600C43A-00; VFD1600C63B-00;
VFD2000C63B-00
Model『MKC-FN1CB』
ITEM Description Qty.
1 Screw M5*0.8*10L 8
2 Bushing Rubber28 2
3 Bushing Rubber 44 4
4 Bushing Rubber 100 2
5 Conduit box cover 1
6 Conduit box base 1
Figure 7-90
Frame G
Applicable models: VFD1850C43A-00; VFD2000C43A-00; VFD2200C43A-00; VFD2500C43A-00;
VFD2500C63B-00; VFD3150C63B-00
Model『MKC-GN1CB』
ITEM Description Qty.
1 Screw M5*0.8*10L 12
2 Bushing Rubber 28 2
3 Bushing Rubber 44 2
4 Bushing Rubber 130 3
5 Conduit box cover 1
6 Conduit box base 1
Figure 7-91
Table 7-90
Table 7-91
