Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-01-41
2: When switching between LOCAL and REMOTE, the drive runs with
REMOTE settings for frequency and operation status.
3: When switching between LOCAL and REMOTE, the drive runs with LOCAL
settings for frequency and operation status.
4: When switching between LOCAL and REMOTE, the drive runs with LOCAL
settings when switched to Local and runs w
ith REMOTE settings when
switched to Remote for frequency and operation status.
 The default of Pr.00-29 is 0, that is, the standard (Hand-Off-Auto) function. Set the AUTO
frequency and operation source with Pr.00-20 and Pr.00-21. Set the HAND frequency and
operation source with Pr.00-30 and Pr.00-31. Select or switch AUTO / HAND mode by using the
digital keypad (KPC-CC01) or setting the multi-function input terminal MIx = 41, 42.
 When you set the external terminal (MI) to 41 and 42 (AUTO / HAND mode), Pr.00-29 = 1,2,3,4
are disabled. The external terminal has the highest command priority, and Pr.00-29 functions in
standard HOA mode.
 If Pr.00-29 is not set to 0, the Local / Remote function is enabled, and the top right corner of digital
keypad KPC-CC01 (optional) displays LOC or REM (the display is available when KPC-CC01 is
installed with firmware version higher than version 1.021). Set the LOCAL frequency and operation
source with Pr.00-20 and Pr.00-21. Set the REMOTE frequency and operation source with Pr.00-
30 and Pr.00-31. Select or switch LOC / REM mode with the digital keypad KPC-CC01 (optional)
or set the multi-function input terminal MIx = 56. The AUTO key of the digital keypad is for the
REMOTE function, and HAND key is for the LOCAL function.
 When you set the external terminal (MI) to 56 for LOC / REM mode selection, if you set Pr.00-29
to 0, then the external terminal function is disabled.
 When you set the external terminal (MI) to 56 for LOC / REM mode selection, if Pr.00-29 is not set
to 0, then AUTO / HAND keys are disabled. In this case, the external terminal has the highest
command priority. 
 The comparison between the setting of each mode and the PLC address:
PLC address /
mode
HOA mode LOC / REM mode HOA mode
HAND-ON AUTO-ON LOC-ON REM-ON OFF
M1090 = 0 0 0 0 1
M1091 = 1 0 0 0 0
M1092 = 0 1 0 0 0
M1100 = 0 0 1 0 0
M1101 = 0 0 0 1 0
00-30
Master Frequency Command Source (HAND)
Default: 0
Settings 0: Digital keypad
1: RS-485 communication input
2: External analog input (Refer to Pr.03-00–03-02)
3: External UP / DOWN terminal (multi-function input terminals)
