Delta C2000 Plus Series User Manual

Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-05-7
 For example: The rated current of a 7.5 HP (5.5 kW) is 25 A. The default is 22.5A.
The setting range is between 40%–120% of rated current.
25 × 40% = 10 A and 25 × 120% = 30 A

05-35
Rated Power for a Permanent Magnet Synchronous AC Motor /
Reluctance Motor
Default: Depending on the
model power
Settings 0.00–655.35 kW
 Set the rated power for the permanent magnet synchronous motor. The default is the drive’s
power value.

05-36
Rated Speed for a Permanent Magnet Synchronous AC Motor /
Reluctance Motor
Default: 2000
Settings 0–65535 rpm
05-37
Number of Poles for a Permanent Magnet Synchronous AC Motor /
Reluctance Motor
Default: 10
Settings 0–65535
05-38
System Inertia for a Permanent Magnet Synchronous AC Motor /
Reluctance Motor
Default: Depending on the
motor power
Settings 0.0–6553.5 kg-cm
2
 Default values are as below:
HP kW Default HP kW Default HP kW Default
1 0.7 3.0 30 22 308.0 215 160 4151.3
2 1.5 6.6 40 30 527.0 250 186 5012.1
3 2.2 15.8 50 37 866.0 300 224 6314.9
5 3.7
25.7
60 45 1082.0
375
280
6314.9
7 5.5
49.6
75 56 1267.6
425
317
6314.9
10 7.5
82.0
100 75 1515.0
475
354
6314.9
15 11 177.0 120 89 2025.8
600
447
6314.9
20 15 211.0 150 112 2447.8
650
485
6314.9
25 18 265.0 175 130 2871.4
750
559
6314.9
05-39
Stator Resistance for a Permanent Magnet Synchronous AC Motor /
Reluctance Motor
Default: 0.000
Settings 0.000–65.535 W
