Fault Code
bit0 bit1 bit2 bit3 bit4 bit5 bit6
current Volt. OL SYS FBK EXI CE
83: Output phase loss V phase (OPHL)
●
84: Output phase loss W phase (OPHL)
●
85: PG ABZ line off (AboF) (PG-02U)
●
86: PG UVW line off (UvoF) (PG-02U)
●
87: Overload protection at low frequency (oL3)
●
89: Rotor position detection error (RoPd)
●
90: Forced to stop (FStp)
●
92: Pulse tuning Ld / Lq error (LEr)
●
93: CPU error 0 (TRAP)
(applied to 230V / 460V models)
●
101: CANopen guarding error (CGdE)
●
102: CANopen heartbeat error (CHbE)
●
104: CANopen bus off error (CbFE)
●
105: CANopen index error (CidE)
●
106: CANopen station address error (CAdE)
●
107: CANopen memory error (CFrE)
●
111: InrCOM time-out error (ictE)
●
112: PM sensorless shaft lock error (SfLK)
●
142: Auto-tune error 1 (no feedback current error)
(AUE1) (applied to 230V / 460V models)
●
143: Auto-tune error 2 (motor phase loss error)
(AUE2) (applied to 230V / 460V models)
●
144: Auto-tune error 3 (no-load current I
0
measuring
error) (AUE3) (applied to 230V / 460V models)
●
148: Auto-tune error 4 (leakage inductance Lsigma
measuring error) (AUE4) (applied to 230V /
460V models)
●
171: Over position error (oPEE)
●
174: Encoder error (EcEr)
●
175: Encoder communication error (EcCe)
●
176: Encoder multi-turn overflows (EcOF)
●
177: Encoder power off (EcNP)
●
178: Encoder multi-turn error (EcMc)
●
179: PG multi-turn read error (PgMr)
●
180: Encoder single-turn error (EcSc)
●
181: PG command error (PgCe)
●
182: Interpolation time error (IPTE)
●
183: Interpolation command failure (IPCM)
●
184: No motion control (NoMo)
●
