Chapter 14 Fault Codes and DescriptionsC2000 Plus
ID* Display on LCD Keypad Fault Name Fault Descriptions
24_2
Motor overheating
(oH3) PT100
Motor overheating (PT100) (Pr.03-00 – Pr.03-02 = 11
PT100). When PT100 input > Pr.06-
the fault treatment acts according to Pr.06-29.
Action and Reset
Action condition PT100 input value > Pr.06-57 setting (default = 7V)
Fault treatment parameter
Pr.06-29
0: Warn and keep operation
1: Fault and ramp to stop
2: Fault and coast to stop
Reset method
When Pr.06-29 = 0 and the temperature < Pr.06-56, oH3 is automatically cleared.
When Pr.06-29 = 1 or 2, oH3 is a “Fault”. You must reset manually.
When Pr.06-29 = 1 or 2, oH3 is a “Fault”, and the fault is recorded.
Cause Corrective Actions
The load is too large
Reduce the load.
Increase the motor capacity.
Ambient temperature is too high
Change the installed place If there are heating devices in the surroundings.
Install / add cooling fan or air conditioner to lower the ambient temperature.
Motor cooling system fault
Check the cooling system to make it work normally.
Operate at low-speed too long
Decrease low-speed operation time.
Replace the motor with a dedicated to VFD model.
Increase the motor capacity.
Accel./Decel. time and working
Increase the setting values for Pr.01-12–Pr.01-19 (accel./decel. time)
V/F voltage is too high
Adjust settings for Pr.01-01–01-08 (V/F curve), especially the setting value for
the mid-point voltage (if the mid-point voltage is set too low, the
load capacity
decreases at low speed).
Check if the motor rated current
matches that on the motor
Reset to the correct motor rated current.
Check if the PT100 is properly set
Check connection of PT100 thermistor.
Check if the setting for stall
Set the stall prevention to the proper value.
Unbalanced three-phase
Replace the motor.
Use remedies to reduce harmonics.
