Chapter 5 Main Circuit TerminalsC2000 Plus
5-18
Frame H
W/T3S/L21 T/L32 +1/DC+R/L11 T/L31 U/T1-/DC- V/T2R/L12 S/L22
 If you install at Ta 40°C (for 460V model names with last digit -21; for 690V model names end with 63B-21) /
50°C (for 460V model names with last digit -00; for 690V model names end with 63B-00) environment, use
copper wires have a voltage rating of 600V and are temperature resistance to 75°C or 90°C.
 If you install at Ta 40°C (for 460V model names with last digit -21; for 690V model names end with 63B-21) /
50°C (for 460V model names with last digit -00; for 690V model names end with 63B-00) above environment,
use copper wires have a voltage rating of 600V and are temperature resistant ntance to 90°C or above.
 For VFD4000C43A-00, VFD4500C43A-00 models: if you install at Ta 40°C above environment, use copper
wires that have a voltage rating of 600V and are temperature resistance to 90°C or above.
 To be UL installation compliant, you must use copper wires when installing. The wire gauge is based on
temperature resistance of 75°C, in accordance with UL requirements and recommendations. Do not reduce
the wire gauge when using high-temperature resistant wire.
Model Name
Main Circuit Terminals
R/L11、R/L12、S/L21、S/L22、T/L31、T/L32、U/T1、
V/T2、W/T3、-/DC-、+1/DC+
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
Max. Wire Gauge Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
VFD2800C43A-00
185 mm
2
*4
(350
MCM*4)
120 mm
2
*4 (4/0 AWG*4)
M8
180 kg-cm
(156.2 lb-in.)
(17.65 Nm)
120 mm
2
*4 (4/0AWG*4) 120 mm
2
*2 (4/0 AWG*2)
M8
180 kg-cm
(156.2 lb-in.)
(17.65 Nm)
VFD3150C43A-00 150 mm
2
*4 (300 MCM*4) 150 mm
2
*4 (300 MCM*4) 150 mm
2
*2 (300 MCM*2)
VFD3550C43A-00 150 mm
2
*4 (300 MCM*4) 150 mm
2
*4 (300 MCM*4) 150 mm
2
*2 (300 MCM*2)
VFD4000C43A-00 150 mm
2
*4 (300 MCM*4) 150 mm
2
*4 (300 MCM*4) 150 mm
2
*2 (300 MCM*2)
VFD4500C43A-00 185 mm
2
*4 (350 MCM*4) 185 mm
2
*4 (350 MCM*4) 185 mm
2
*2 (350 MCM*2)
VFD2800C43C-21 95 mm
2
*4 (3/0 AWG*4) 95 mm
2
*4 (3/0 AWG*4) 95 mm
2
*2 (3/0 AWG*2)
VFD3150C43C-21 120 mm
2
*4 (4/0 AWG*4) 120 mm
2
*4 (4/0 AWG*4) 120 mm
2
*2 (4/0 AWG*2)
VFD3550C43C-21 120 mm
2
*4 (250 MCM*4) 120 mm
2
*4 (250 MCM*4) 120 mm
2
*2 (250 MCM*2)
VFD4000C43A-21 150 mm
2
*4 (300 MCM*4) 150 mm
2
*4 (300 MCM*4) 150 mm
2
*2 (300 MCM*2)
VFD4500C43C-21 185 mm
2
*4 (350 MCM*4) 185 mm
2
*4 (350 MCM*4) 185 mm
2
*2 (350 MCM*2)
VFD4000C63B-00 95 mm
2
*4 (3/0 AWG*4) 95 mm
2
*4 (3/0AWG*4) 95 mm
2
*2 (3/0 AWG*2)
VFD4500C63B-00 95 mm
2
*4 (3/0 AWG*4) 95 mm
2
*4 (3/0AWG*4) 95 mm
2
*2 (3/0 AWG*2)
VFD5600C63B-00 120 mm
2
*4 (250 MCM*4) 120 mm
2
*4 (250 MCM*4) 120 mm
2
*2 (250 MCM*2)
VFD6300C63B-00 150 mm
2
*4 (300 MCM*4) 150 mm
2
*4 (300 MCM*4) 150 mm
2
*2 (300 MCM*2)
VFD4000C63B-21 95 mm
2
*4 (3/0 AWG*4) 95 mm
2
*4 (3/0 AWG*4) 95 mm
2
*2 (3/0 AWG*2)
VFD4500C63B-21 95 mm
2
*4 (3/0 AWG*4) 95 mm
2
*4 (3/0 AWG*4) 95 mm
2
*2 (3/0 AWG*2)
VFD5600C63B-21 120 mm
2
*4 (250 MCM*4) 120 mm
2
*4 (250 MCM*4) 120 mm
2
*2 (250 MCM*2)
VFD6300C63B-21 150 mm
2
*4 (300 MCM*4) 150 mm
2
*4 (300 MCM*4) 150 mm
2
*2 (300 MCM*2)
