Delta C2000 Plus Series User Manual

Chapter 14 Fault Codes and DescriptionsC2000 Plus
14-67
ID* Display on LCD Keypad Fault Name Fault Descriptions
65
Hardware error of PG
card (PGF5)
Hardware error of PG card
Action and Reset
Action condition
1. The PG card (PG01U /
PG02U) can only be used with the permanent
magnetic motor. When the power is ON and Pr.00-04 =
29 pole section
shows 0 or 7 (wiring error or no U/V/W signal input), the PGF5 error will be
activated.
2. The drive receives the operation command right after the
power is ON,
meanwhile, the PG card is not ready yet.
Action time Act immediately
Fault treatment parameter N/A
Reset method Manual reset
Reset condition Reset after cycle the power.
Record Yes
Cause Corrective Actions
Wiring error or there is no U/V/W
signal input
Re-connect the cables correctly
Encoder failure Verify if it is the UVW encoder
The setting of encoder parameter
is incorrect
Choose the correct setting of Pr. 10-00
If the motor selection switch of PG
card on the correct position
Check if it is the UVW encoder or Delta encoder
PG card selection is incorrect Install the correct PG card
