Delta CP2000 Series User Manual

Chapter 12 Description of Parameter SettingsCP2000
12.1-00-14
 When you do not set Pr.00-29 to 0, the Local / Remote function is enabled, and the top right
corner of digital keypad KPC-CC01 (firmware version 1.021 and above) displays “LOC” or “REM”.
Set the REMOTE frequency and operation source with Pr.00-20 and Pr.00-21. Set the LOCAL
frequency and operation source with Pr.00-30 and Pr.00-31. Select or switch Local / Remote
mode with the digital keypad KPC-CC01 or set the multi-function input terminal MIx=56. The
AUTO key of the digital keypad is for the REMOTE function, and HAND key is for the LOCAL
function.
 When you set the external terminal (MI) to 56 for LOC / REM mode selection, if you set Pr.00-29
to 0, then the external terminal function is disabled.
 When you set the external terminal (MI) to 56 for LOC / REM mode selection, if Pr.00-29 is not
set to 0, then AUTO / HAND key is disabled, and the external terminal has the highest command
priority.
 Following table is the corresponded setting value for the PLC address:
PLC address /
Mode
HOA mode LOC / REM mode HOA mode
HAND-ON AUTO-ON LOC-ON REM-ON OFF
M1090 = 0 0 0 0 1
M1091 = 1 0 0 0 0
M1092 = 0 1 0 0 0
M1100 = 0 0 1 0 0
M1101 = 0 0 0 1 0
Master Frequency Command Source (HAND)
Default: 0
Settings 0: Digital keypad
1: RS-485 serial communication
2: External analog input (Pr.03-00)
3: External UP/DOWN terminal
6: CANopen communication card
8: Communication card (does not include CANopen card)
 Determines the master frequency source in HAND mode.
Operation Command Source (HAND)
Default: 0
Settings 0: Digital keypad
1: External terminals
2: RS-485 serial communication
3: CANopen communication card
5: Communication card (does not include CANopen card)
 Determines the operation frequency source in HAND mode.
 Use Pr.00-20 and Pr.00-21 to set the frequency source and the operation source in AUTO mode,
and use Pr.00-30 and Pr.00-31 to set the frequency source and operation source in HAND mode.
Select or switch AUTO / HAND mode by using the digital keypad KPC-CC01 or setting the
multi-function input terminal (MI).

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
