Delta CP2000 Series User Manual

Chapter 12 Description of Parameter SettingsCP2000
12.1-12-3
Number of Motors to be Connected
Default: 1
Settings 1–8
 Number of Motors: maximum of eight motors. After setting the number of connected motors, the
multi-function output terminals automatically follow the setting as shown in the table below.
Pr.12-01 01 02 03 04 05 06 07 08
Pr.02-13 55 55 55 55 55 55 55 55
Pr.02-14 56 56 56 56 56 56 56
Pr.02-15 57 57 57 57 57 57
Pr.02-36 58 58 58 58 58
Pr.02-37 59 59 59 59
Pr.02-38 60 60 60
Pr.02-39 61 61
Pr.02-40 62
Table 1: Setting of Multi-function Output Terminal for Circulating Motors
Operating Time of Each Motor (minutes)
Default: 0
Settings 0–65500 minutes
 Sets the fixed time for circulation. If Pr.12-02 = 0, stop the timing. The currently running motors
continue operating until a Stop command is given.
Delay Time due to the Acceleration (or the Increment ) at Motor Switching (seconds)
Default: 1.0
Settings 0.0–3600.0 seconds
 Sets the delay time when switching motors. When the currently running motors reach the time
setting for Pr.12-02, the CP2000 uses the delay time setting for Pr.12-03 and then switches to run
the next motors.
Delay Time due to the Deceleration (or the Decrement) at Motor Switching (seconds)
Default: 1.0
Settings 0.0–3600.0 seconds

Delay time due to Fixed Quantity Circulation at Motor Switching (seconds)
Default: 10.0
Settings 0.0–3600.0 seconds
 Sets the fixed quantity circulation with PID
Sequential Diagram
In this mode, the CP2000 can control up to four motors to increase flow quantity and pressure
range control. When controlling the flow quantity, the motors are in parallel connection. When
controlling the pressure range, the motors are in series connection.

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
