Ultron DPS Series
126
No. Item Description
1
Sheet Tabs
(Day/ Week/ Month/
Year/ Since Reset)
Tap the sheet tabs to view the kWh statistics and
column charts of different time scales.
2 Column Chart
1. Shows the UPS’s main input kWh statistics, with
time on X-axis and kWh on Y-axis.
2. Tap the column on the chart, and the corresponding
piece of data will appear below the chart.
3
Search Tick
Setup Icon ( )
Tap ( ), and you can set the date and time for the
'
Search Tick
' to view the corresponding column chart.
4 Search Tick
Shows the date and time that has been set via ( ).
5
Present/Peak/
Low/ Sum (kWh/d)
Regardless of different kWh statistics sheets, these
four items only indicate today’s statistics: the present
value/ the highest value (so far)/ the lowest value (so
far)/ the sum (so far).
6 Last Reset Date
The last date when '
Clear Kilowatt Hour
' was
executed.
To Next Page
