127
7.6 UPS Settings
This chapter lists all the UPS setting items for your reference (not including the setting items
for the optional accessories). Some items will show up only under certain conditions. Please
refer to
7.1 LCD Display Hierarchy
for details.
7.6.1 Bypass Setting
Path: → Bypass Setting
Item Description
Bypass Frequency Range
Set up the bypass output’s frequency range.
Bypass Voltage (Max.)
Set up the bypass output’s maximum voltage.
Bypass Voltage (Min.)
Set up the bypass output’s minimum voltage.
ECO Voltage Range
Set up the bypass output’s voltage range in ECO mode.
7.6.2 Mode Setting
Path: → Mode Setting
Item Description
On-Line Mode
Set up the UPS in On-Line mode. In On-Line mode, it is the
inverter to supply power to the connected loads.
ECO Mode
Set up the UPS in ECO mode. In ECO mode, it is the bypass to
supply power to the connected loads. It is suggested that you set
the UPS in ECO mode only when there is stable main AC power.
Otherwise, power supply quality will be compromised.
Frequency
Conversion Mode
Set up the UPS in Frequency Conversion mode. In Frequency
Conversion mode, it is the inverter to supply power to the
connected loads with a fixed output frequency. Please note that the
output will be terminated once the inverter is turned off.
NOTE:
Frequency Conversion mode is only applicable to single
UPS but not to parallel UPSs.
