Delta DPS Series User Manual

Ultron DPS Series
60
UPS Capacity
DPS
300kVA
DPS
400kVA
DPS
500kVA
DPS
600kVA
Output
Rated current at 220V 454A 606A 758A 909A
Recommended cable size
(L1/ L2/ L3/ N)
120 mm
2
× 2 PCS
(250 kcmil
× 2 PCS)
120 mm
2
× 3 PCS
(250 kcmil
× 3 PCS)
150 mm
2
× 3 PCS
(300 kcmil
× 3 PCS)
185 mm
2
× 3 PCS
(400 kcmil
× 3 PCS)
Maximum cable size
(L1/ L2/ L3/ N)
185 mm
2
× 2 PCS
(400 kcmil
× 2 PCS)
185 mm
2
× 3 PCS
(400 kcmil
× 3 PCS)
240 mm
2
× 3 PCS
(500 kcmil
× 3 PCS)
300 mm
2
× 3 PCS
(600 kcmil
× 3 PCS)
Cable lug width
30 mm
(1.18")
30 mm
(1.18")
34 mm
(1.34")
38 mm
(1.50")
Maximum cable lug width
38 mm
(1.50")
38 mm
(1.50")
42 mm
(1.65")
48 mm
(1.89")
Screw size M12
Battery
Nominal discharge current
(Condition: 2V per cell)
658A 877A 1096A 1315A
Maximum discharge
current
(Condition: 1.75V per cell)
752A 1003A 1253A 1504A
Recommended cable size
(+/ -/ N)
185 mm
2
× 2 PCS
(400 kcmil
× 2 PCS)
150 mm
2
× 3 PCS
(300 kcmil
× 3 PCS)
150 mm
2
× 4 PCS
(300 kcmil
× 4 PCS)
240 mm
2
× 4 PCS
(500 kcmil
× 4 PCS)
Maximum cable size
(+/ -/ N)
300 mm
2
× 2 PCS
(600 kcmil
× 2 PCS)
240 mm
2
× 3 PCS
(500 kcmil
× 3 PCS)
240 mm
2
× 4 PCS
(500 kcmil
× 4 PCS)
300 mm
2
× 4 PCS
(600 kcmil
× 4 PCS)
Cable lug width
38 mm
(1.50")
34 mm
(1.34")
34 mm
(1.34")
42 mm
(1.65")
Maximum cable lug width
48 mm
(1.89")
42 mm
(1.65")
42 mm
(1.65")
48 mm
(1.89")
Screw size M12
Tightening Torque
M12 = 500 ± 10kgf-cm
(434 ± 8.7lb-in)

Delta DPS Series Specifications

General

Frequency	50/60 Hz
Battery Type	Sealed Lead-Acid (SLA)
Communication Interface	RS-232, USB, SNMP (Optional)
Output Voltage	220/230/240VAC
Topology	Double Conversion
Form Factor	Tower or Rackmount
Power Factor	0.9
Type	Online UPS
Protection Features	Short Circuit
