DVP02TK-S/DVP02TU-S Temperature Control Module Manual
2-32
_2
RS-485 Communication Setting Address = 0x0F09, written value is 0x00XY
Bit2 Stop Bits
0 1-bit (default)
1 2-bit
Bit1~Bit0 Parity
0 Even (default)
1 Odd
2 None
3 Reserved
Data Length Stop Bits Parity
Y
value
bit3 bit2 bit1 bit0
Data Bits Stop Bits Parity
0: 7
1: 8
0: 1-bit
1: 2-bit
0: Even; 1: Odd;
2: None; 3: reserved
0 0 0 0 0 7 1 even
1 0 0 0 1 7 1 odd
2 0 0 1 0 7 1 none
3 0 0 1 1 7 1 even
4 0 1 0 0 7 2 even
5 0 1 0 1 7 2 odd
6 0 1 1 0 7 2 none
7 0 1 1 1 7 2 even
8 1 0 0 0 8 1 even
9 1 0 0 1 8 1 odd
A 1 0 1 0 8 1 none
B 1 0 1 1 8 1 even
C 1 1 0 0 8 2 even
D 1 1 0 1 8 2 odd
E 1 1 1 0 8 2 none
F 1 1 1 1 8 2 even
