Chapter 3 Featured Functions
Ethernet St
atistics
Item Description
Interface Specify one interface for Ethernet Statistics.
Drop Events
The cumulative number of events in which packets were dropped on
the interface because of lack of resources. This number does not
specify the number of packets that were dropped but the number of
times the packets were dropped.
Packets The cumulative number of packets received on the interface.
Broadcast Packets
The cumulative number of broadcast packets received on the
interface.
Multicast Packets
The cumulative number of multicast packets received on the
interface.
CRC Errors
The cumulative number of packets received on the interface that
have a length (excluding framing bits, but including FCS octets) of
between 64 and 1518 octets. That had either a bad frame check
sequence (FCS) with an integral number of octets (FCS error) or a
bad FCS with a non integral number of octets (alignment error).
Under Size Packets
The cumulative number of packets received on the interface that
were less than 64 octets in length (excluding framing bits, but
including FCS octets) and that were well formed.
Over Size Packets
The cumulative number of packets received on the interface that
were more than 1518 octets in length (excluding framing bits, but
including FCS octets) and that were well formed.
3-105
