DVS Series Managed Industrial Ethernet Switches User’s Manual
Multiple Port Mirroring
Description Factory Default
Monitored Port
Specify the monitored port or ports for monitoring. Unchecked
Session Mode
Specify whether the port mirroring is enabled:
 Enable: The port mirroring is enabled. The setting applies to all
interfaces.
 Disable: The port mirroring is disabled. The setting applies to all
interfaces.
Note:
When you configure the session mode for an individual
interface, it is applied to all interfaces. You can select
Enable from the Session Mode drop-down list and control
the port mirroring for individual interfaces. If you want to
disable the port mirroring, make sure the direction is not
configured for the interfaces. If the direction is configured
of the interfaces and you want to disable port mirroring,
select the check box of the interface, and click Delete to
remove the port mirroring configuration for the interface.
None
Watch Direction
Specify the direction in which the port mirroring occurs:
 Tx and Rx: Both outgoing and incoming traffic are mirrored.
 Tx Only: Only outgoing traffic is mirrored.
 Rx Only: Only incoming traffic is mirrored.
None
Mirror Port
Specify which port is the mirror port. None
Status Table
Item Description
Monitored Port This field displays the monitored port number.
Mirror Port
This field displays the destination port or monitored interface. Only
one port can be the mirror port. This port is used as the mirror port
for all ports which you configure port mirroring.
Session Mode
The port mirroring status of the port.
 Enable: The port mirroring is enabled.
 Disable: The port mirroring is disabled.
Direction
The direction of the port mirroring.
 Tx and Rx: Both outgoing and incoming traffic are mirrored.
 Tx Only: Only outgoing traffic is mirrored.
 Rx Only: Only incoming traffic is mirrored.
3-124
