DVS Series Managed Industrial Ethernet Switches User’s Manual
B-4
Address Offset Data Type Description
0x00A0 1 word
DI 1 Status
0x0000: OFF
0x0001: ON
0x00A1 1 word
DI 2 Status
0x0000: OFF
0x0001: ON
Port Information
0x1000 ~ 0x1009 1 word
Port 1 to 10 Status
0x0000: Link down
0x0001: Link up
0x0002: Disable
0x1100 ~ 0x1109 1 word
Port 1 to 10 Communication Format
0x0000: 10M,Half
0x0001: 10M,Full
0x0002: 100M,Half
0x0003: 100M,Full
0x0004: 1G,Full
0x1200 ~ 0x1209 1 word
Port 1 to 10 Flow Control
0x0000: OFF
0x0001: ON
0x1300 ~ 0x1309 1 word
Port 1 to 10 MDI/MDIX Setting
0x0000: Auto
0x0001: MDI
0x0002: MDIX
0x1400 ~ 0x14C7 20 words
Port 1 to 10 Description
EX: 10/100/1000TX,RJ45
Word 0 Hi byte = '1'
Word 0 Lo byte = '0'
Word 1 Hi byte = '/'
Word 1 Lo byte = '1'
Word 2 Hi byte = '0'
Word 2 Lo byte = '0'
Word 3 Hi byte = '/'
Word 3 Lo byte = '1'
Word 4 Hi byte = '0'
Word 4 Lo byte = '0'
Word 5 Hi byte = '0'
Word 5 Lo byte = 'T'
Word 6 Hi byte = 'X'
Word 6 Lo byte = ','
Word 7 Hi byte = 'R'
Word 7 Lo byte = 'J'
Word 8 Hi byte = '4'
Word 8 Lo byte = '5'
Word 9 Hi byte = '\0'
Word 9 Lo byte = '\0'
0x1500 ~ 0x1509 1 word
Port 1 to 10 bandwidth overload
0x0000: OFF
0x0001: Port X bandwidth overload
