DVS Series Managed Industrial Ethernet Switches User’s Manual
B-6
Address Offset Data Type Description
SPF DDM Information
0x4000 1 word Port 1 to Port 3 Port No.
0x4100 20 words
Port 1 to Port 3 Model Name
Example: LCP-1250B4QDRH
Word 0 Hi byte = 'L'
Word 0 Lo byte = 'C'
Word 1 Hi byte = 'P'
Word 1 Lo byte = '-'
Word 2 Hi byte = '1'
Word 2 Lo byte = '2'
Word 3 Hi byte = '5'
Word 3 Lo byte = '0'
Word 4 Hi byte = 'B'
Word 4 Lo byte = '4'
Word 5 Hi byte = 'Q'
Word 5 Lo byte = 'D'
Word 6 Hi byte = 'R'
Word 6 Lo byte = 'H'
Word 7 Hi byte = '\0'
Word 7 Lo byte ='\0'
0x4200 2 words
Port 1 to Port 3 Temperature
Word 0 = Temperature MSB
Word 1 = Temperature LSB
0x4300 2 words
Port 1 to Port 3 Voltage
Word 0 = Vcc MSB
Word 1 = Vcc LSB
0x4400 2 words
Port 1 to Port 3 TX Power
Word 0 = TX Power MSB
Word 1 = TX Power LSB
0x4500 2 words
Port 1 to Port 3 RX Power
Word 0 = RX Power MSB
Word 1 = RX Power LSB
0x4600 1 words
Port 1 to Port 3 Link Status
0x0000: Link down
0x0001: Link up
Alarm
0x5000 1 word
Switch cold start alarm
0x0000: OFF
0x0001: ON
0xFFFF: Disable
0x5001 1 word
Switch warm start alarm
0x0000: OFF
0x0001: ON
0x5004 1 word
Power state on alarm
0x0000: OFF
0x0001: ON
0x5005 1 word
Power state off alarm
0x0000: OFF
0x0001: ON
