Delta NT Series - Page 27

Chapter 4 Installation & Wiring
22
D
W
H
Figure 4-7
836XQLWSUR¿OHGLPHQVLRQVWDEOH
(Model 400/ 230Vac only)
Figure 4-7
Rating
(kVA)
Width
(mm)
Depth
(mm)
Height
(mm)
100~160K -
12P
1200 830 1700
160~200K -
6P
Figure 4-8
Bottom View
(Front)
