Chapter 4 Installation & Wiring
44
6. Connect the provided + & - cooper bars to the inverter’s + & - bus bars
Take out the provided screws and + & - cooper bars from the package, and
FRQQHFWWKHPWRWKHLQYHUWHU¶VEXVEDUVVKRZQLQFigure 4-39. The size of
the provided + & - cooper bars are the same.
Figure 4-39
INVERTER’s + & - BUS BARS
+ & - COOPER BARS PACKED
IN THE PACKAGE (THE SIZE
OF + & - COOPER BARS
ARE THE SAME)
