Delta R2-EC 004 Series User Manual

R2-ECx004 User Manual Object Dictionary
5-21
5
5.6.2 DO Setting Value (6200h)
This object sets the values of the DO channels of R2-EC0004 and R2-EC2004 (8 output
channels as a set).
R2-EC0004
Index
Sub-
index
Name
Data
type
Access
PDO
mapping
Value
6200h
0
DO Setting Value
USINT
RO
NO
2
1
Port 1 DO
CH0 - 7 Setting Value
USINT
RW
YES
0 to 255
Default: 0
2
Port 1 DO
CH8 - 15 Setting Value
USINT
RW
YES
0 to 255
Default: 0
R2-EC2004
Index
Sub-
index
Name
Data
type
Access
PDO
mapping
Value
6200h
0
DO Setting Value
USINT
RO
NO
4
1
Port 0 DO
CH0 - 7 Setting Value
USINT
RW
YES
0 to 255
Default: 0
2
Port 0 DO
CH8 - 15 Setting Value
USINT
RW
YES
0 to 255
Default: 0
3
Port 1 DO
CH0 - 7 Setting Value
USINT
RW
YES
0 to 255
Default: 0
4
Port 1 DO
CH8 - 15 Setting Value
USINT
RW
YES
0 to 255
Default: 0
