8 Settings
Installation and Operation Manual for Inverter RPI M50A_12s V1 EU EN 2017-03-09
120
Setting options
Parameter Description Setting range
Mode
Switch the function on and off.
ON | OFF
V1s
The lower voltage limit for feeding inductive reactive power.
220.0 .. 292.0 V
V2s
The upper voltage limit for feeding inductive reactive power.
220.0 .. 292.0 V
Qs limit
The limit value for inductive reactive power. The value is set as a per-
centage of the nominal apparent power S
n
. This value is connected to
the parameter V2s.
ind 63% .. 1% | 0%
V1i
The upper voltage limit for feeding capacitive reactive power.
184.0 .. 254.0 V
V2i
The lower voltage limit for feeding capacitive reactive power.
184.0 .. 254.0 V
Qi limit
The limit value for capacitive reactive power. The value is set as a
percentage of the nominal apparent power S
n
. This value is con-
nected to the parameter V2i.
cap 63% .. 1% | 0%
T Delay
Delay time before feeding reactive power.
0 .. 120 s
Lock-in power
The upper limit of the active power range in which the function is
active. The value is set as a percentage of the nominal active power.
Cannot be changed
Lock-out power
The lower limit of the active power range in which the function is
active. The value is set as a percentage of the nominal active power.
Cannot be changed
Menu item path
Main Menu > Active/Reactive Pwr > Reactive Power Ctrl
> Q(V)
Calling up the menu item
E-Today: 0kWh
Power: 0W
Status: On Grid
10.Sep 2014 15:32
1. If the default information is displayed, press any button to open the main menu.
Otherwise, press the
EXIT
button repeatedly until the main menu is displayed.
Inverter Info.
General Settings
Install Settings
Active/Reactive Pwr
FRT
2. Use the and buttons to select the Active/Reactive Pwr entry and then press
the
ENT
button.
Password 0 * * *
energy production.
Adj. would affect
Warning:
3. This function is protected with password 5555.
Use the
and buttons to set the individual numerals.
Press the
ENT
button to confirm a number.
Reactive Power Ctrl
Active Power Ctrl
4. Use the and buttons to select the Reactive Power Ctrl entry and then press
the
ENT
button.
Q(V)
Constant Q
Cos phi (P)
Constant cos phi
5. Use the and buttons to select the Q(V) entry and then press the
ENT
button.
