Installation and Operation Manual for Inverter RPI M50A_12s V1 EU EN 2017-03-09
8 Settings
Setting the mode
Qs limit: Ind 44%
V2s: 253.0V
V1s: 248.4V
Mode: OFF
6. Use the and buttons to select the Mode entry and then press the
ENT
button.
→ The shape of the arrow changes
, the value can be changed.
The currently set mode is displayed after the entry.
7. Use the and buttons to select a mode and then press the
ENT
button.
Changing the settings
Qs limit: Ind 44%
V2s: 253.0V
V1s: 248.4V
Mode: OFF
8. Use the and buttons to select a parameter and then press the
ENT
button.
→ The shape of the arrow changes
, the parameter can be changed.
The currently set value is displayed after the entry.
9. Use the and buttons to configure the value and then press the
ENT
button.
