Delta UPS602N2004N035 - Chapter 6: Operation Modes; Standby Mode; On-Line Mode; Bypass Mode

34
Amplon N Series
Chapter 6 : Operation Modes
NOTE :
1. Please refer to &KDSWHU2SHUDWLRQ3DQHO to learn how to operate the
operation panel and understand the display meaning.
2. Each of the display diagrams shown in this chapter is for reference only.
Actual display depends on the operation of the UPS.
6.1 Standby Mode
NOTE :
:KHQWKH836LVLQWKHVKXWGRZQVWDWXVDQGLVWKH¿UVWWLPHWREHIHGZLWK
the utility AC power, the bypass will supply power to the output directly and
the bypass output voltage and frequency won’t be controlled.
After the UPS is connected to the AC utility, it will supply power to the UPS and the
batteries will be charged.
6.2 On-line Mode
In online mode, the connected loads are supplied by the inverter, which derives its
power from the utility AC power, and the UPS charges the batteries and provides
power protection to its connected loads.
6.3 Bypass Mode
NOTE :
:KHQWKH836LVLQWKHVKXWGRZQVWDWXVDQGLVWKH¿UVWWLPHWREHIHGZLWK
the utility AC power, the bypass will supply power to the output directly and
the bypass output voltage and frequency won’t be controlled.
In bypass mode, the critical loads are directly supplied by the utility power and the
batteries are charged. The default setting of the UPS is set in 'Bypass Mode'.
