Delta VFD-B Series User Manual

Chapter 2 Installation and Wiring|VFD-B-P Series
Revision April 2009, SW V1.00 2-13
AC motor drive with heatsink MKB-PHC
VFD055B43P-C
VFD075B43P-C
VFD110B43P-C
VFD150B43P-C
AC motor drive with heatsink MKB-PHC1
VFD055B43P-C1
VFD075B43P-C1
VFD110B43P-C1
VFD150B43P-C1
3
2
3
.
0
[
1
2
.
7
2
]
3
5
5
.
0
[
1
3
.
9
8
]
3
7
5
.
0
[
1
4
.
7
6
]
3
9
0
.
0
[
1
5
.
3
5
]
M6*P1.0(8X)
200.0 [7.87]
219.0 [8.62]
232.0 [9.13]
300.0 [11.81]
252.0 [9.92]
82.0 [3.23]
89.1 [3.51]
198.0 [7.80]
M6*P1.0(8X)
54.5 [2.15]
170.5 [6.71]
61.6 [2.43]
54.5 [2.15]
252.0 [9.92]
390.0 [15.35] 375.0 [14.76] 355.0 [13.98] 323.0 [12.72]
300.0 [11.81]
232.0 [9.13]
219.0 [8.62]
200.0 [7.87]
NOTE
1. This is only the dimension for the AC motor drive with heatsink, it needs to be used with a capacity module to
be a complete product.
2. VFDXXXB43P-C: frame C with heatsink type C0 (this type is only for China market).
VFDXXXB43P-D: frame D with heatsink type D0 (this type is only for China market).
VFDXXXB43P-C1: frame C with heatsink type C1 (this type is only for China market).
VFDXXXB43P-D1: frame D with heatsink type D1 (this type is only for China market).

Delta VFD-B Series Specifications

General

Series	VFD-B
Cooling Method	Fan cooling
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Communication	RS-485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Altitude	1000m (Derating required above 1000m)
