5-10
5-6 Over Heating oH1
Reduce load
Remove the clog
Replace cooling fan
Is airway of cooling fan clogged
Is load too heavy
Is cooling fan running
No
Yes
Yes
No
Yes
No
No
Yes
Yes
No
Hybrid servo drive is
overheated
Heat sink is
overheated
Is the temperature of heat sink
higher than 90
°
C
Temperature detection circuit on
circuit board malfunctions. Please
contact Delta for assistance.
It's likely hybrid servo drive breaks down or
malfunctions due to noise. Please contact
Delta for assistance.
Is environment temperature within
regulated range
Adjusted the
to
environment
temperature regulated range
5-7 Over Load oL
Reduce load or increase the
capacity of hybrid servo drive
Hybrid servo drive is
overloaded
To Next Page
