Delta VFD110VL43A-J User Manual

1. Use and Installation
1-3
1-2 Product Specifications
Specifications of 230V Series
Frame No. C D E2
Model No. VFD-_ _VL_ _A-J 055 075 110 150 185 220 300 370
Power (KW) 5.5 7.5 11 15 18.5 22 30 37
Horse Power (HP) 7.5 10 15 20 25 30 40 50
Output Current for
Continuous Operation
Over 60 sec (A)
33 46 62 90 119 119 180 248
Output
Output Current for
Continuous Operation
Over 20 sec (A)
37 54 70 106 140 140 204 292
Input Current (A)
25 31 47 60 80 90 106 126
Tolerable Input
Voltage Variation
Three-phase 200~240V 50/60Hz
Tolerable Supply
Voltage Variation
±10% (180~264V)
Power
Supply
Tolerable Supply
Frequency Variation
±5% (47~63Hz)
Weight (kg) 8 10 10 13 13 13 36 36
Specifications of 460V Series
Frame No. C D E1 E2
Model No. VFD-_ _VL_ _A-J 055 075 110 150 185 220 300 370 450 550 750
Power (KW) 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Horse Power (HP) 7.5 10 15 20 25 30 40 50 60 75 100
Output Current for
Continuous Operation
Over 60 sec (A)
21 27 36 46 58 62 102 124 155 187 255
Output
Output Current for
Continuous Operation
Over 20 sec (A)
25 32 42 54 68 78 120 146 182 220 300
Input Current (A)
14 18 24 31 39 47 56 67 87 101 122
Tolerable Input
Voltage Variation
Three-phase 380~480V, 50/60Hz
Tolerable Supply
Voltage Variation
±10% (342~528V)
Power
Supply
Tolerable Supply
Frequency Variation
±5% (47~63Hz)
Weight (kg) 8 10 10 13 13 13 36 36 36 50 50
Common Features
Control method SVPWM
Speed Detector Resolver / Incremental Encoder
Speed Command Input DC 0~10V, 3-point calibration of analog input is supported
Pressure Command Input DC 0~10V, 3-point calibration of analog input is supported
Pressure Feedback Input DC 0~10V
General Purpose Input Signal 5 ch DC24V 8mA
General Purpose Output Signal 2 ch DC24V 50mA, 1 ch Relay output
Analog Output Voltage 1 ch dc 0~10V
Optional
Peripheral
Speed Feedback PG
Card
Mandatory (Refer to Appendix A-5)
