3. Machine Adjustment Procedure
3-3
If the “End” message (as shown in the left figure) is displayed on the display
area for about one second, it means that data has been accepted and
automatically stored in the internal memory
If the setting data is not accepted or its value exceeds the allowed range, this
error message will be displayed
Keypad Panel Operation Procedure
To shift data
Setting direction
Setting Mode
Setting parameters
(When operation source is digital keypad)
START
GO START
NOTE:
In the selection mode, press
to set the parameters.
Success to
set parameter.
Input data error
or
NOTE
：
In the parameter setting mode, you can press
to return the selecting mode.
To Next Page
