Delta VFD110VL43A-J User Manual

1-4
Braking Resistor Mandatory (Refer to Appendix A-1)
Pressure Sensor
Mandatory (It must has an output signal ranging within 0~10V, which can be configured
by Parameters 03-10~03-11;
The maximum pressure can be configured by Parameter 00-08)
Accessories
EMI Filter
Optional (Refer to Appendix A-7)
Motor Protection
Electronic thermal relay protection
Over Current
Protection
Over current protection is activated at 300% of the rated current
Ground Leakage
Current Protection
Activated when the leakage current is higher than 50% of the drive’s rated current
Voltage Protection
Over Voltage Level: Vdc>400/800 V; Low Voltage Level: Vdc<200/400 V
Input Power Supply
Over Voltage
Protection
Metal Oxide Varistor (MOV)
Protection
Feature
Over Temperature
Protection
Built-in temperature sensor
Protection Level
NEMA 1/IP20
Operation
Temperature
-10°C~45°C
Storage Temperature
-20°C~60°C
Humidity
Below 90% RH (non-condensing)
Vibration
1.0G below 20Hz, 0,6G at 20~60 Hz
Cooling System
Forced air cooling
Environment
Installation Altitude
Altitude below 1,000m, keep from corrosive gasses, liquid and dust
International Certification
