Appendix A Optional Accessories
A-5
Dimensions of Brake Unit
Brake Unit: VFDB2015, VFDB2022, VFDB4030, and VFDB4045
80.0 [3.15]
121.0 [4.76]
189.5 [7.46]
200.0 [7.87]
130.0 [5.12]
R3.3 [R0.13]
ACT.
YELLOW
CHARGE
GREEN
ERR.
RED
