Delta VFD110VL43A-J User Manual

4-4
Parameter
code
Function of the parameter Settings
Default
value
VF
FOCPG
FOCPM
00-09 Pressure control mode
0: Speed control
1: Pressure control
0 ○ ○ ○
00-10 Speed bandwidth 0~40Hz 20 ○ ○
a
00-11
Pressure feedback filtering
time PO
0.000~1.000 second 0.000 ○ ○ ○
a
00-12
Pressure command filtering
time PI
0.000~1.000 second 0.000 ○ ○ ○
a
00-13
Flow command filtering time
QI
0.000~1.000 second 0.000 ○ ○ ○
a
00-14
Percentage for the pressure
command value (Max)
0.0~100.0% 100.0 ○ ○ ○
a
00-15
Percentage for the pressure
command value (Mid)
0.0~100.0% 50.0 ○ ○ ○
a
00-16
Percentage for the pressure
command value (Min)
0.0~100.0% 0.0 ○ ○ ○
a
00-17
Percentage for the flow
command value (Max)
0.0~100.0% 100.0 ○ ○ ○
a
00-18
Percentage for the flow
command value (Mid)
0.0~100.0% 50.0 ○ ○ ○
a
00-19
Percentage for the flow
command value (Min)
0.0~100.0% 0.0 ○ ○ ○
a
00-20 P gain 1 0.0~1000.0 50.0 ○ ○ ○
a
00-21 I integration time 1 0.00~500.00 seconds 2.00 ○ ○ ○
a
00-22 P gain 2 0.0~1000.0 50.0 ○ ○ ○
a
00-23 I integration time 2 0.00~500.00 seconds 2.00 ○ ○ ○
a
00-24 P gain 3 0.0~1000.0 50.0 ○ ○ ○
a
00-25 I integration time 3 0.00~500.00 seconds 2.00 ○ ○ ○
a
00-26 Pressure stable region 0~100% 25 ○ ○ ○
a
00-27 Base pressure 0.0~100.0% 1.0 ○ ○ ○
a
00-28 Depressurization speed 0~100% 25 ○ ○ ○
a
00-29
Ramp up rate of pressure
command
0~1000ms 0 ○ ○ ○
a
00-30
Ramp down rate of pressure
command
0~1000ms 100 ○ ○ ○
a
00-31
Ramp up rate of flow
command
0~1000 ms 80 ○ ○ ○
a
00-32
Ramp down rate of flow
command
0~1000 ms 80 ○ ○ ○
