Delta VFD110VL43A-J User Manual

4-12
03 Digital/Analog Input/Output Parameters a the parameter can be set during
operation
Parameter
code
Function of the parameter Settings
Default
value
VF
FOCPG
FOCPM
03-00
Multi-function input
command 3 (MI3)
0 ○ ○ ○
03-01
Multi-function input
command 4 (MI4)
0 ○ ○ ○
03-02
Multi-function input
command 5 (MI5)
0: No function
44: Injection signal input
45: Confluence/Diversion signal input
46: Reserved
47: Multi-level pressure PI command 1
48: Multi-level pressure PI command 2
0 ○ ○ ○
a
03-03 Digital input response time 0.001~ 30.000 sec 0.005 ○ ○ ○
a
03-04
Digital input operation
direction
0～65535
0 ○ ○
a
03-05
Multi-function output 1
(Relay 1)
11 ○ ○ ○
a
03-06
Multi-function Output 2
(MO1)
0 ○ ○ ○
a
03-07
Multi-function Output 3
(MO2)
0: No function
1: Operation indication
9: Hybrid servo drive is ready
11: Error indication
44: Displacement switch signal
45: Motor fan control signal
0 ○ ○ ○
a
03-08
Multi-function output
direction
0～65535
0 ○
a
03-09
Low-pass filter time of
keypad display
0.001~65.535 seconds 0.010 ○ ○ ○
03-10
Maximum output voltage for
pressure feedback
5.0~10.0 V 10.0 ○ ○ ○
03-11
Minimum output voltage for
pressure feedback
0.0~10.0 V 0.0 ○ ○ ○
a
03-12 Reserved
03-13
Confluence Master/Slave
Selection
0: No function
1: Master 1
2: Slave/Master 2
3: Slave/Master 3
0 ○ ○ ○
03-14
Slave's proportion of the
Master’s flow
0.0~65535.5 % 100.0 ○ ○ ○
a
03-15
Source of frequency
command
0: Digital keypad
1: RS485 Communication
2~5: Reserved
0 ○ ○ ○
a
03-16
Limit for the Slave reverse
depressurization torque
0~500% 20 ○ ○ ○
a
03-17 Slave’s activation level 0.0~100.0% 50.0 ○ ○ ○
