4-22
01 Motor Parameters a the parameter can be set during
operation
Control mode
Control mode VF FOCPG FOCPM
Factory default: 5
Settings
0：V/F
1: Reserved
2: Reserved
3: FOCPG
4: Reserved
5: FOCPM
6: Reserved
This parameter determines the control mode of this AC motor.
0: V/F control, the user can design the required V/F ratio. It is used for induction motors.
1~2: Reserved
3: FOC vector control + Encoder. It is used for induction motors.
4: Reserved
5: FOC vector control + Encoder. It is used for synchronous motors.
6: Reserved
a
Source of operation command
Control mode VF FOCPG FOCPM
Factory default: 1
Settings 0: The operation command is controlled by the digital operation panel
1: The operation command is controlled by the external terminals. The
STOP button on the keypad panel is disabled
2: The operation command is controlled by the communication interface.
The STOP button on the keypad panel is disabled
For the operation command, press the PU button to allow the “PU” indicator to be lit. In this case,
the RUN, JOG, and STOP button are enabled.
Motor’s maximum operation frequency
Control mode VF FOCPG FOCPM
Factory default:
60.00/50.00
Settings 50.00 – 600.00Hz
Set the maximum operation frequency range of the motor. This setting is corresponding to the
maximum flow for the system.
Motor’s rated frequency
Control mode VF FOCPG FOCPM
Factory default:
60.00/50.00
Settings 0.00~600.00Hz
Typically, this setting is configured according to the rated voltage and frequency listed in the
specifications on the motor’s nameplate. If the motor is intended for 60Hz, set this value as 60Hz;
if the motor is intended for 50Hz, set this value as 50Hz.
Motor’s rated voltage
Control mode VF FOCPG
Factory default: 220.0/440.0
Settings 230V series: 0.1 – 255.0V
