Denon AVR-S700W Service Manual

MAIN
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R5417,5418 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5419-5422 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5423 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5424 nsp RES,CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5425 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5426 252310006506S PTCTHEMISTORS,CHIP
(
115'C
)
CRTPRF18BB471Q
B
1
R5427 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5429 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5430,5431 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5432 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5433 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5513 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5514 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5515,5516 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5517,5518 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5519-5522 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5523 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5524 nsp RES,CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5525 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5526 252310006506S PTCTHEMISTORS,CHIP
(
115'C
)
CRTPRF18BB471Q
B
1
R5527 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5529 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5530,5531 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5532 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5533 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5613 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5614 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5615,5616 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5617,5618 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5619-5622 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5623 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5624 nsp RES,CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5625 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5626 252310006506S PTCTHEMISTORS,CHIP
(
115'C
)
CRTPRF18BB471Q
B
1
R5627 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5629 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5630,5631 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5632 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5633 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5713 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5714 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5715,5716 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5717,5718 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5719-5722 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5723 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5724 nsp RES,CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5725 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5726 252310006506S PTCTHEMISTORS,CHIP
(
115'C
)
CRTPRF18BB471Q
B
1
R5727 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5729 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5730,5731 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5732 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5733 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5801,5802 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT 2
R5803 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5804 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5805 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5806 nsp RES,CARBON(1/5W,20Kohm,J) CRD20TJ203T 1
R5807,5808 nsp RES,CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 2
R5809 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5810 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5811 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R5812-5818 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 7
R5819 nsp RES,M-OXIDEFILM(1W/100ohm) CRG1SANJ101RT 1
R5820 nsp RES,M-OXIDEFILM(1W/33ohm) CRG1SANJ330RT 1
R5821 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT 1
R5823,5824 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT 2
R5826,5827 943124500350M RES,CEMENT(0.02ohm/3W) CRF3EJR02 2
R5830 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R5831 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5832 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5833 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R5834 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R5835 nsp RES,CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
R5836 nsp RES,CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R5837 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5838 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R5839,5840 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R5841 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5842 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
CAPACIITORS GROUP
C5107 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5108 13405014940AS CAP,ELECT(63V/100uF) CCEA1JH101T 1
C5109 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5110 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5111 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5113 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5120 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5207 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5208 13405014940AS CAP,ELECT(63V/100uF) CCEA1JH101T 1
C5209 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5211 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5213 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5307 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5308 13405014940AS CAP,ELECT(63V/100uF) CCEA1JH101T 1
C5309 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5310 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5311 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5313 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5407 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5408 13405014940AS CAP,ELECT(63V/100uF) CCEA1JH101T 1
C5409 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5410 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5411 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5413 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5507 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
4

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
